Black Aluminium Shell Amplifier / HiFi Control Knob
Black Aluminium Shell Amplifier / HiFi Control Knob
A series of round aluminium rotary control knobs in a matching style. These knobs have a silver bevelled edge and silver position indicator. They feature a side grip and a plastic splined-shaft fixing insert. They are constructed from an aluminium outer shell with a plastic internal insert that contains the splined fixing hole.
| Quantity | Unit Price |
|---|---|
| 1+ | £0.79 |
| 5+ | £0.632 |
| 10+ | £0.553 |
| 20+ | £0.474 |
| 50+ | £0.395 |
| 100+ | £0.316 |
Couldn't load pickup availability
Fitting
| Knob Type | Rotary |
|---|---|
| Shaft Type | Splined |
| Shaft Fixing | Push-Fit |
| Hole Size | 6mm |
Appearance
| Identity Colour | Black |
|---|---|
| Body Colour | Black |
| Accent Colour | |
| Position Indicator Colour | Silver |
| Position Indicator Shape | Line |
Measurements
| Minimum Shaft Depth | 9.0mm |
|---|---|
| Maximum Shaft Depth | 15.1mm |
| Body Diameter | 12.8mm |
| Maximum Diameter | 13.0mm |
| Width | mm |
| Length | mm |
| Height | 16.9mm |
| Additional Measurements | |
| Unit Weight | 2.14g |
Hole Type
Splined Hole
Knobs designed for splined shafts have holes with multiple grooves or ridges that correspond to the splines on the shaft. This splined hole creates a very tight and secure fit, preventing any movement between the knob and the shaft.
The position indicator can be placed in any of 18 different directions, in increments of 20°
The ridged interior of the hole ensures a strong connection, capable of handling high torque and frequent adjustments without the risk of slippage.
A control knob with a splined hole will not fit onto a round or D typ shaft.
